General Purpose ABS Resin

Conductive ABS is made from ABS raw materials by mixing carbon fiber, carbon black, metal fiber, metal powder, anti-static masterbatch, etc.  It can achieve the functions of anti-static, static dissipation, dust absorption prevention, conductive and electromagnetic interference (EMI).  Conductive ABS has excellent comprehensive physical and mechanical properties, impact resistance, dimensional stability, easy flow, low water absorption, chemical resistance, good molding and machining, water resistance Inorganic salt, alkali, acid and other products.

Product parameter

Basic Properties Melt Flow rate 200℃ 5kg ASTM D-1238 0.5g /10min

Melt flow rate 200℃ 10kg ISO 1133 5 g/10min

Physical Properties Specific Gravity ASTM D-792 1.03 23/23℃

Mechanical properties IZOD Impact Strength 1/4" ASTM D-256 35 kg.cm/cm

Bending Strength ASTM D-790 620 kg/cm2

Elongation ASTM D-790 40%

Bending elasticity ASTM D-790 2.1 104kg/cm2

Rockwell Hardness ASTM D-785 102 R

Tensile Strength ASTM D-638 390 kg/cm2

IZOD Impact Strength 1/8" ASTM D-256 40 kg.cm/cm

Thermal Properties Thermal Deformation Temperature Annealing ASTM D-648 97(207) ℃(°F)

Unannealed ASTM D-648 87(189) ℃(°F)

Vica Softening Point ASTM D-1525 103(217) ℃(°F)

Flammability File NO.E196075 1/16"HB
